Item # 64AY37ACS-1C, OPGW Optical Ground Wire

Applications

OPGW cable is suited for installation on new power lines with double function of a ground wire and a communication wire, especially for installation on normal voltage and extra high voltage power lines.   OPGW can replace conventional ground wire of old power lines with increasing fiber communications functions. OPGW cables conduct short circuit current and provide lighting resistance.

For more information, please visit Down Lead Clamp For OPGW.

Construction

OPGW cable has two constructions:

Central loose tube type---The fibers are placed loosely in a sealed and water resistant central, stainless steel tube filled with water blocking gel. This tube provides protection to the fiber during installation and operation under severe environmental conditions.  The stainless steel tube may also be aluminum cladded depending on the engineering requirements. The stainless optical tube is located at the center of the cable protected by single or multiple layers of aluminum clad steel, aluminum alloy wires, or steel wires. The metallic wires provide mechanical strength to withstand severe installation and operating conditions, while achieving conductivity to control temperature rise during short circuit conditions.

Each optical fiber is clearly distinguishable utilizing a fiber identification system consisting of coloring and the number of ring marks on it. This compact design features high mechanical strength and fault current rating within a smaller diameter. The smaller diameter also results in excellent sag tension performance.

Multi loose tube type--- The fibers is placed loosely in a sealed and water resistant stainless steel tube filled with water blocking gel. Two or three stainless steel optical tubes are helically stranded in the inner layer of a multiple-layer cable.  The multi loose tube type is designed mostly for very high fiber count requirement over 48 with the maximum fiber count reaching 144. The multi loose tube type can meet the requirement of huge cross and large current capacity.

Are you interested in learning more about Suspension Clamp Manufacturer? Contact us today to secure an expert consultation!

The optical fiber is made of high pure silica and germanium doped silica. UV curable acrylate material is applied over fiber cladding as optical fiber primary protective coating. The detail data of optical fiber performance are shown in the following table.

Optical fiber uses special spun device successfully controlled the value of PMD, and makes sure that it can keep stable in cabling

Standards

• IEC -1 Optical fiber Part 1: Generic specifications
• IEC -2 Optical fiber Part 2: Product specifications
• ITU-T G.652 Characteristics of a single-mode optical fiber cable
• ITU-T G.655 Characteristics of a non-zero dispersion-shifted single-mode optical fiber and Cable
• EIA/TIA 598  Color code of fiber optic cables
• IEC -4-10 Aerial optical cables along electrical power lines &#; Family specification for OPGW
• IEC -1-2 Optical fiber cables-Part 1-2: Generic specification - Basic optical cable test procedures
• IEEE- IEEE Standard for testing and performance for optical ground wire (OPGW) for use on electric utility power lines
• IEC Aluminum &#; clad steel wire for electrical purposes
• IEC Aluminum magnesium-silicon alloy wire for overhead line conductors
• IEC Round wire concentric lay overhead electrical stranded conductors
• Fiber is Corning SMF-28e+ Optical Fiber

Options

• Hardware for Installation

Notes

If you are looking for more details, kindly visit opgw joint box.

• Reel lengths must be defined at time of purchase to assist client with reducing waste, and to reduce splicing required during installation.
• Please contact AWG for full detailed technical specifications, including PLS CADD data or Stress Creep data.
